Elite Water Fill Funnel

Product Description



Water fill kit (funnel) for Cynosure Elite Laser compatible with:

  • MPX
  • ELNL
  • Elite+
  • ELMD
  • Apogee 6200/9300

Filling the Water Reservoir

1. Connect the funnel assembly to the quick-disconnect on the front of the water tank behind the front door.


2. Fill the reservoir with distilled water halfway into the overflow area of the reservoir.


3. Plug in the laser, turn on the main circuit breaker, and then cycle the power for five seconds.


4. Add distilled water to the reservoir to force air from the lower reservoir into the overflow area. Cycle the power again for 5 seconds.


5. Repeat step 4 until all of the air has been purged from the system.


6. Fill the overflow area of the reservoir until the screen displays “FULL.”



$50.00
